Regular price
$159.00
Regular price
Sale price
$159.00
Taxes included.
Quantity
Couldn't load pickup availability
.
Case Size: 140x108x43.5mm
Weight: 491g
Weight: 491g
Display
Display Type: TN
Size: 2.8 inch
Panel Active Area: 43.20*57.60mm
Resolution: 240x320 Pixel
Number of Colors: 262K
Size: 2.8 inch
Panel Active Area: 43.20*57.60mm
Resolution: 240x320 Pixel
Number of Colors: 262K
Power
AC Input: 100V ~ 240V（50Hz/60Hz）
DC Input: 10V~30V
Charge Power:
Discharge Power:
DC Input: 10V~30V
Charge Power:
AC Input: 100W(±10%)
1 port: Max. 60W
2 ports: 50W + 50W
3 ports: 33W + 33W + 33W (Total power divided by 3)
4 ports: 25W × 4
2 ports: 50W + 50W
3 ports: 33W + 33W + 33W (Total power divided by 3)
4 ports: 25W × 4
DC Input: 240w(±10%) 60W *4
Discharge Power:
Main port: 5W
Balance port: Max. 10W（LiPo/4S）
Balance port: Max. 10W（LiPo/4S）
Charge and Discharge
Charge Current: 0.1A~0.5A（±0.1A） 0.6A~6.0A（±10%）
Balance Current: Max. 600mA
Balance Current: Max. 600mA
Working Mode:
LiPo/LiFe/Li-ion/LiHV: Balance CHG, Charge, Discharge, Storage
NiMH/NiCd: Normal, Discharge, Repeak, CYCLE_D_C, CYCLE_C_D
Pb: Normal, AGM Charge, Cold Charge, Discharge
NiMH/NiCd: Normal, Discharge, Repeak, CYCLE_D_C, CYCLE_C_D
Pb: Normal, AGM Charge, Cold Charge, Discharge
Battery Types/Cells:
LiPo/LiHV/LiFe/LiIon: 1-4S
NiMH/NiCd: 1-8S
Pb: 3S/6S
NiMH/NiCd: 1-8S
Pb: 3S/6S
Working and Storage
Operating temperature: 0℃-40℃
Working humidity: 5% ~ 75% RH (Non-condensing)
Storage temperature: -10℃ ~ 70℃
Storage humidity: 5% ~ 75% RH (Non-condensing)
Working humidity: 5% ~ 75% RH (Non-condensing)
Storage temperature: -10℃ ~ 70℃
Storage humidity: 5% ~ 75% RH (Non-condensing)
