Reedy RT3005A Digital Aluminum Hi-Speed Brushless Servo (High Voltage)
Specifications:
Input: 6.0 - 8.4V
Speed (sec/60°):
@6.0V: 0.076
@7.4V: 0.060
@8.4V: 0.055
Torque:
@6.0V: 298.57 oz-in (21.5 kg-cm)
@7.4V: 347.18 oz-in (25.0 kg-cm)
@8.4V: 416.62 oz-in (30.0 kg-cm)
Dimensions: 40x20x39.3mm
Weight: 75g
Spline: 25T
Specifications:
Input: 6.0 - 8.4V
Speed (sec/60°):
@6.0V: 0.076
@7.4V: 0.060
@8.4V: 0.055
Torque:
@6.0V: 298.57 oz-in (21.5 kg-cm)
@7.4V: 347.18 oz-in (25.0 kg-cm)
@8.4V: 416.62 oz-in (30.0 kg-cm)
Dimensions: 40x20x39.3mm
Weight: 75g
Spline: 25T
